Meraki MX68W Next-Gen firewall with Enterprise License

Meraki MX68W Next-Gen firewall with Enterprise License

SKU: MX68W~PVAR Categories: , Brand: Cisco Meraki


Like all of Meraki’s firewall appliances, the Cisco Meraki MX68W is easy to learn and operate. Also, it’s 100% cloud-managed. This is where the MX series truly shines. The Meraki MX68W can be remotely deployed in minutes. And, most actions in the cloud interface are point and click. Security settings are simple to synchronize across thousands of sites.

The Meraki MX68W pushes 450Mbps of data at once. Therefore, it’s perfectly suitable for setups of up to 50 users. Its Auto VPN technology securely connects branches in 3 clicks. This is done through an intuitive, web-based dashboard. And, it can support up to 50 connections at once at up to 200 Mbps. To secure a site in minutes simply add your MX68 to the dashboard. Then, enable intrusion prevention. Finally, just select the level of threat protection you want.

Tell me about Meraki MX68W licensing. What is this, and why do I need it?

Importantly, the Meraki MX68W requires valid licensing to operate. These are on a “per device, per year” basis. The MX series has  two licenses: Enterprise and Advanced Security. These are available in 1, 3, and 5 year options. They can be bought through your authorized Meraki partner.

Remember, without this licensing, your Cisco Meraki MX68W will cease to function. So, 30 days prior to your license’s expiration date the administrators on your account will be notified. Then, another e-mail will be sent 3 days prior to expiration.

Lastly, an expiration banner will also be displayed in the Meraki dashboard during this time. However, you can reactivate your account at any point in the future, even after expiration. All you do is, just add the necessary number of valid licenses.

Do you know why the Cisco Meraki MX68W is a great fit for the healthcare sector?

Working in IT networking and security in the healthcare sector is a pretty unique experience. Why? because keeping technology running is a critical part of patient care and saving lives. Can you say ‘pressure’? Especially as threats like ransomwares are becoming so much more prevalent and sophisticated. Click here to learn how Meraki is ideal for meeting the challenges unique in this field.

Meraki MX68W At a Glance

  • Stateful Firewall Throughput
450 Mbps
  • Security Throughput
300 Mbps
  • Max VPN Throughput
200 Mbps
  • Recommended LAN Users
  • SD-WAN Ready
  • VPN Tunnels


Meraki MX67 and MX68 datasheet

Additional information

Weight 3.64 lbs
Dimensions 7.00 × 11.20 × 1.10 in

SDWan-Plus, No License, Advanced, Enterprise


Hardware Only, 1 Year, 3 Years, 5 Years, 7 Years, 10 Years

Product Description Cisco Meraki MX68W - security appliance
Device Type Security appliance
Form Factor Desktop
Ports Qty 10
Frequency Band 2.4 GHz, 5 GHz
Performance Firewall throughput: 450 Mbps u00a6 VPN throughput: 200 Mbps u00a6 Advanced security throughput: 300 Mbps
Capacity Maximum number of users: 50 u00a6 Maximum number of configured SSIDs: 4
Cellular Protocol LTE
Power Over Ethernet (PoE) Supported PoE+
Manufacturer Warranty Limited lifetime warranty
Built-in Devices Modem
Connectivity Technology Wireless, wired
Data Transfer Rate 1.3 Gbps
Network / Transport Protocol L2TP, IPSec, PPPoE, DHCP
Routing Protocol Static IP routing, MPLS
Remote Management Protocol HTTP
Features Firewall protection, DHCP support, NAT support, load balancing, layer 7 switching, VLAN support, traffic shaping, content filtering, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), firmware upgradable, wall mountable, IPSec Virtual Private Network (VPN), Quality of Service (QoS), MPLS VPN, 3G/4G USB Dongle Support, static routing, 802.1x authentication, Link Aggregation, VPN client, IP Security (IPSec) support, DMZ support
Encryption Algorithm WPA, WPA-PSK, WPA2-Enterprise, WEP
Authentication Method Radio Service Set ID (SSID)
Compliant Standards C-Tick, CB, IC, FCC, RoHS, CISPR, IPsec/IKE
Antenna External detachable
Antenna Qty 2
Directivity Omni-directional
Interfaces 2 x 1000Base-T - RJ-45 (WAN) u00a6 8 x 1000Base-T - RJ-45 u00a6 2 x 1000Base-T (PoE+) - RJ-45 u00a6 1 x USB 2.0 - Type A u00a6 2 x antenna - RP-SMA
Power Device External power adapter
Installed Qty 1
Max Supported Qty 1
Power Consumption Operational 89 Watt
Power Provided 100 Watt
Service & Support Limited warranty - advance hardware replacement - lifetime - response time: next day
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 5 - 95%
