Fortinet FortiExtender 201E bridge WWAN desktop, wall-mountable FEX-201E


Fortinet FortiExtender 201E – Bridge – WWAN – GigE – wall-mountable

SKU: FEX-201E Categories: , Brand: Fortinet


Fortinet FortiExtender 201E – Bridge – WWAN – GigE – wall-mountable

Enterprises are increasingly taking advantage of wireless WAN technology not only as a backup for their wired WAN connections, but also as the primary WAN connection in locations such as; small branch offices, retail “pop-up” stores, point of sale systems and kiosks. A FortiExtender 3G/4G LTE wireless WAN extender enables a reliable and stable connection to support these applications.

Key Selling Points
Provides a secondary failover WAN link to improve business continuity
Provides a primary WAN link for retail POS, remote ATM machines and remote kiosk systems
Reduces WAN TCO through single pane of glass management integration

Additional information

Weight 2.5214 lbs
Dimensions 261 × 250 × 56 in
Product Description Fortinet FortiExtender 201E - bridge - WWAN - desktop, wall-mountable
Device Type Bridge
Enclosure Type Desktop, wall-mountable
Cellular Protocol UMTS, WCDMA, HSPA+, LTE, XLTE
Features 2T2R MIMO technology, 15.4 W PoE power budget
Compliant Standards IEEE 802.3af, IEEE 802.3at, EN55022, ICES-003, EN55024, FCC, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, PTCRB, EN 61000, LVD, Directive 2004/108/EC, Directive 2006/95/EC, NCC, EN 300 328, IEC 60950-1:2005, EN 301 489, EN 50385, RSS-210 Issue 7, RSS-Gen Issue 2, RSS-102 Issue 4, FCC Part 15 Class B, R&TTE Directive 1999/5/EC, EN 301 893
Localization North America, South America, Europe
Connectivity Technology Wired
Status Indicators Status
Type 1 x wireless cellular modem
Interfaces WAN: 5 x 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 u00a6 Antenna: 3 x SMA u00a6 Antenna: 1 x GPS connector
Expansion Slots 2 (total) / 2 (free) x SIM
Antenna External detachable
Antenna Qty 3
Power Device Power injector
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 5 - 95%
