Startech .com KVM Switchbox2 Computer2 Local User3840 x 21606 x USB6 x DisplayPortTAA Compliant P2DD46A22-KVM-SWITCH

$676.09 KVM Switchbox

SKU: P2DD46A22-KVM-SWITCH Categories: , Brand: Startech

Description KVM Switchbox

This Dual-Monitor KVM Switch enables users to switch between two desktops that are USB-A and DisplayPort enabled. It allows for sharing of dual-4K 60Hz DisplayPort monitors, a keyboard and mouse, two USB 5Gbps devices, and two USB 2.0 HID devices.

RS232 Serial Control

This 2-Port KVM Switch provides control using serial commands, enabling users to switch between host ports, modify hotkeys, and perform various other functions. The RS232 host ports offer additional flexibility by allowing the switching of an RS232 device between two desktop computers.

Near Instantaneous Switching

DisplayPort EDID and USB Emulation technology enable near-instant switching of a keyboard, video, and mouse. DisplayPort EDID emulation remembers application window placement, while USB Emulation ensures compatibility with combination keyboards/mice, as well as keyboards featuring additional function keys.

Dual-4K 60Hz DisplayPort Monitors

This TAA-Compliant KVM Switch supports dual-4K 60Hz DisplayPort monitors, making it an ideal choice for working with high-resolution graphics or video. It also features MST pass-through, enabling the connection of additional monitors through daisy chaining – when using an MST Hub or the Video Output Ports located on the monitor.

Customizable Switching

This Universal KVM Switch offers multiple switching options, including hotkey, on-screen display, or push-button switching. Hotkeys provide independent switching of USB/Video, Audio, and RS232, allowing for audio playback from one computer while controlling the other or switching without interrupting serial communication. An audible buzzer confirms hotkey input, and LEDs provide a visual indication of the selected host.

Enhance Productivity and Device Management with the Connectivity Tools Application

Developed to improve performance and security, Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

  • Advanced Windows Layout Utility: Setup and save custom windows layouts.
  • MAC Address Pass-Through Utility: Improve network security.
  • USB Event Monitoring Utility: Track and log connected USB devices.
  • Wi-Fi Auto Switch Utility: Enable users to quickly access faster network speeds via wired LAN.

Additional information

Weight 3.36 lbs
Dimensions 10.00 × 5.10 × 1.60 in
Package Contents <li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>KVM Switchbox, <li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>2 x DisplayPort Cables, <li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>2 x USB-A to USB-B Cables, <li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1 x Power Supply, <li data-list="bullet"><span class="ql-ui" contenteditable="false"></span>1 x Quick-Start Guide
Product Type KVM Switchbox
Manufacturer Part Number P2DD46A22KVMSWITCH
Manufacturer Website Address
Packaged Quantity 1
Limited Warranty 2 Year
Product Name KVM Switchbox
Brand Name
Input Voltage Range 100-240 VAC
Environmentally Friendly Yes
Environmental Certification RoHS, WEEE
Maximum Video Resolution 3840 x 2160
Maximum Data Transfer Rate 640 MB/s
Number of USB Ports 6
DisplayPort Yes
USB Standard USB 3.2
Number of DisplayPorts 6
Number of Computers Supported 2
Number of Local Users Supported 2
TAA Compliant Yes
Input Current 1 A
Minimum Operating Temperature 32&deg;F (0&deg;C)
Maximum Operating Temperature 104&deg;F (40&deg;C)
GTIN 0065030900485
UPC 065030900485
EAN 0065030900485
UNSPSC 43211601
