Geist MN02E1R0-10L138-2TL6A0H10-S 10-Outlets PDU
PDU distributes AC power to multiple servers and balances the load on the servers.
Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs.

SKU: I20382L Categories: , Brand: Vertiv


Geist MN02E1R0-10L138-2TL6A0H10-S 10-Outlets PDU

The I20382L provides real-time power metrics to help prevent overloads and safely optimize load levels. The unit offers local and IP-based monitoring with quick access to real-time power metrics and environmental sensor data. Using Visible Light Communication (VLC) technology, I20382L optically transmits power usage data from its LED display to a handheld device over the Geist Mobile App, presenting comprehensive real-time power usage data down to the phase and circuit levels. With the Geist Upgradeable hot-swap technology, users may easily upgrade PDUs to the latest available technology by replacing the Interchangeable Monitoring Device (IMD) module; all without causing any interruption.

Additional information

Weight 17 lbs
Dimensions 8.50 × 17.00 × 1.72 in
Package Contents MN02E1R0-10L138-2TL6A0H10-S 10-Outlets PDU, Adjustable Mount Brackets,
Product Type PDU
Input Voltage 120 V AC
Manufacturer Part Number I20382L
Manufacturer Website Address
Limited Warranty 5 Year
Output Voltage 120 V AC
Input Current 20 A
Management HTTP, HTTPS (TLS 1.2), SMTP, SMTPS (TLS 1.2), ICMP, DHCP, IPv4, IPv6, Syslog, SNMP v1/v2c/v3, JSON, JSON API, RSTP,
Manufacturer Vertiv
Product Model MN02E1R0-10L138-2TL6A0H10-S
Product Name MN02E1R0-10L138-2TL6A0H10-S 10-Outlets PDU
Mount Type Rack-mountable
Protection Type Overload Protection
Rack Height 1U
Brand Name Geist
Plug/Connector Type NEMA L6-20P
Country of Origin United States
Receptacle Type U-Lock IEC 60320 C13
Environmentally Friendly Yes
Environmental Certification RoHS
Network (RJ-45) Yes
PDU Type Monitored
Mounting Orientation Horizontal
Power Rating (Watt) 3300 W
Receptacle Detail 10 x U-Lock IEC 60320 C13
Plug/Connector Detail 1 x NEMA L6-20P
UNSPSC 39121017
