Vertiv Geist rPDU DU00X5B1-48CF17-2S02A9K00-S-A 48-Outlets PDUBasicUniversal Input48 x Combination C13/C19230 V AC, 415 V AC0UVertical… U1079


Geist rPDU DU00X5B1-48CF17-2S02A9K00-S-A 48-Outlets PDU
Provide circuit protection and easy configuration for trouble-free access.
Basic PDU is the space-saving and cost-effective way to deliver power.

SKU: U1079 Categories: , Brand: Vertiv


Geist rPDU DU00X5B1-48CF17-2S02A9K00-S-A 48-Outlets PDU

Basic rPDUs deliver reliable power to critical IT equipment within a rack or cabinet.


  • Reliable rack power distribution.
  • Every unit is 100% tested for reliability and functionality.
  • Simple and convenient configuration options for cord lengths and chassis colors.
  • Standard three-year warranty, upgraded to a five-year warranty with product registration.

Additional information

Weight 35 lbs
Dimensions 2.30 × 3.80 × 6.00 in
Product Type PDU
Input Voltage 230 V AC, 415 V AC
Manufacturer Part Number U1079
Manufacturer Website Address
Limited Warranty 5 Year
Input Current 32 A
Length 66.3"
Manufacturer Vertiv
Product Model DU00X5B1-48CF17-2S02A9K00-S-A
Product Name rPDU DU00X5B1-48CF17-2S02A9K00-S-A 48-Outlets PDU
Mount Type Rack-mountable, Cabinet-mountable
Protection Type Overcurrent Protection, Double Pole
Product Series rPDU
Rack Height 0U
Brand Name Geist
Plug/Connector Type Universal Input
Country of Origin United States
Phase Single Phase/Three Phase
Receptacle Type Combination C13/C19
Environmentally Friendly Yes
Environmental Certification RoHS
PDU Type Basic
Mounting Orientation Vertical
Power Rating (Watt) 22 kW
Receptacle Detail 48 x Combination C13/C19
Plug/Connector Detail 1 x Universal Input
UNSPSC 39121017
