APC Smart-UPS X SMX750C UPS 675 Watt 750 VA with SmartConnect


APC Smart-UPS X SMX750C – UPS (rack-mountable / external) – AC 120 V – 675 Watt – 750 VA – Ethernet, USB, serial – output connectors: 8 – 2U – black – with APC SmartConnect – for P/N: SCL500RM1UC, SCL500RM1UNC, SMTL1000RM2UC, SMTL750RM2UC, SRT1000RMXLA-NC

SKU: SMX750C Categories: , , Brand: APC


The APC Smart-UPS X SMX750C UPS is a high density, double-conversion on-line power protection unit with scalable runtime.

APC – The absolute leader in battery backup

From battery backups that safeguard against outages, to full-scale data center infrastructure. From surge protection and power conditioning to rack mounts and a host of other accessories. APC can help your home and business become more efficient, reliable, and connected.

The APC Smart-UPS series are a hugely popular and successful line of power backup systems. They go from entry-level up to full-on enterprise grade products. They are trusted by millions of IT professionals throughout the world to protect equipment and critical data from costly interruptions.

They supply reliable, network-grade power reliably and efficiently. Entry level models such as the SMC1000C and SMC1500C are an affordable choice for small and medium businesses looking to protect small networking devices, point-of-sale equipment and entry level servers.

And the extended run models like the SMT2200s accept external battery packs for long runtime to power critical servers, security and communication systems through outages that could last hours. Smart-UPS provides availability and manageability to your network so you can focus on business growth instead of business downtime. Smart-UPS is EcoStruxure enabled.

APC Smart-UPS – Something for everybody

The Smart-UPS line is extensive. For the sake of simplicity, the original Smart-UPS line is listed here according to power rating (in volt-amps). Simply click to learn more about some of the APC Smart-UPS models rated for: 420 VA, 500 VA, 1000 VA, 1440 VA, 1500 VA, 1920 VA, 2200 VA, 2880 VA, 3000 VA, and 5000 VA.

Smart-UPS accessories

Smart-UPS accessories include various backplate PDU options, external standard and switched PDU options, matching battery cabinets for extending run time(Smart-UPS XL only), management devices, service products, and mounting options. These accessories can customize your solution to increasing availability, adaptability, serviceability, manageability, and performance. Call Corporate Armor at 866-530-8335 or email us for more info.


One feature that stands out on the APC Smart-UPS series is APC’s SmartConnect technology. This allows your UPS to be cloud-enabled. That means you can login via a secure portal via any internet-connected device. Then you can view the status of your UPS, receive notifications, get firmware updates and more.

So for those who don’t have time to monitor the UPS, this can be quite valuable. In addition, the UPS also has both line interactive topology (via an automatic voltage regulator), and uses a clean pure sine wave form for output.

This makes it compatible with most any computer or audio gear. Smart-UPS provides availability and manageability to your network so you can focus on business growth instead of business downtime. Smart-UPS is EcoStruxure enabled. Be sure to give Corporate Armor a call at 866-530-8335, or reach out at [email protected] so we can answer all your APC Smart-UPS questions!



  • Adjustable voltage sensitivity
  • Automatic restart of loads after UPS shutdown
  • Adjustable voltage sensitivity
  • User-replaceable batteries


Read more


APC Smart-UPS: The world’s most popular for a reason!



Additional information

Weight 120.35 lbs
Dimensions 630.00 × 600.00 × 250.00 in
Product Description APC Smart-UPS X SMX750C - UPS - 675 Watt - 750 VA - with APC SmartConnect
Device Type UPS - rack-mountable / external
Rack Size 2U
Input Voltage AC 120 V
Output Voltage AC 120 V u00b1 2% - 50/60 Hz
Power Capacity 675 Watt / 750 VA
Input Connectors 1 x power NEMA 5-15P
Output connectors 8 x power NEMA 5-15R
Battery Lead acid expandable
Run Time (Up To) 8 min at full load u00a6 25.6 min at half load u00a6 50.99 min at 200 Watts u00a6 17.24 min at 500 Watts
Networking Ethernet, USB, serial
Remote Management Protocol DHCP, IPv4
Included Accessories Tower stand
Color Black
Environmental Standards ENERGY STAR
Manufacturer Warranty 3-year warranty
Bundled with APC SmartConnect
UPS Technology Line interactive
Input Voltage Range AC 82 - 144 V
Input Voltage Range (Adjustable) AC 75 - 154 V
Frequency Provided 50/60 Hz
Frequency Required 47 - 63 Hz
Power Output Connectors Details 8 x power NEMA 5-15R
Surge Suppression Yes
Surge Energy Rating 540 Joules
Circuit Protection Circuit breaker
Efficiency 98.73% at 100% Green mode (on-line)
Power Factor (PF) 0.9
Type Expandable
Technology Lead acid
Features Audible alarm, emergency power off, LCD display, Automatic Voltage Regulation (AVR), LED indicators, hot-swappable batteries, Green Function, 1 switched outlet group, EcoStruxure Ready
Remote Management Interface Ethernet, USB, serial
Interfaces 1 x management (USB) u00a6 1 x EPO (emergency power off) u00a6 1 x serial - RJ-45 u00a6 Management (Ethernet)
Expansion Slots 1 SmartSlot
Cables Included Power cable - integrated
Rack Mounting Kit Included
Compliant Standards cUL, UL 1449, UL 1778, FCC Part 15, RoHS, REACH
Service & Support Limited warranty - 3 years u00a6 Limited warranty - batteries - 2 years
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 0 - 95% (non-condensing)
Sound Emission 45 dBA
