CyberPower SM10KAPMA 3-Phase UPS Power Modules – 10000VA Hot-Swappable


CyberPower SM10KAPMA 3-Phase Modular UPS Power Modules Capacity: 10-20 kVA / 10-20 kW. Redundancy: (N+1) capable. Power Factor (PF): 1.0. Topology: Double-Conversion. Waveform: Sine Wave. High Density: Yes – 2U. Warranty: 1 year.

SKU: SM10KAPMA Categories: , , Brand: Cyber Power


The CyberPower SM10KAPMA 3-Phase UPS Power Modules are ultra-robust units. They are capable of handling brief overcurrents of up to 150%. Indicator lights show the status of each Power Module and the high-density design puts 10KVA of power in just 2U of space. It includes a One-Year Limited Warranty., and is for CyberPower 3-Phase Modular UPS Smart App Online Series models SM020KAMFA and SM040KAMFA.


CyberPower UPS Systems is a popular US manufacturer of uninterruptible power supplies, surge protectors and other backup power solutions. Some of its more popular products are the affordable line-interactive UPS devices.

CyberPower also manufactures home office and professional grade UPS systems, PDUs, surge protectors, mobile chargers and connectivity products. They range from consumer grade to IT professional and enterprise. They’re very intent to providing a full range of power management products and solutions. The mission of CyberPower UPS is to help you power, monitor and protect critical equipment and data.

Wherever you are, whenever you need power, CyberPower has got you. They offer a huge line of accessories that charge, split, convert, and adapt power to fit your needs.

We are thrilled to be working with them, and are ready to answer your questions and save you money on your next CyberPower purchase, so reach out to us, or call Corporate Armor at 877-449-0458. We can’t wait to serve you!


CyberPower SM10KAPMA 3-Phase UPS Power Modules

  • One-Year Limited Warranty
  • Optional 20KVA UPS Input/Output
  • Extra disconnect point for easy bypass during repairs or maintenance




Additional information

Weight 51.2 lbs
Dimensions 23.20 × 17.20 × 3.30 in
Product Type Double Conversion Online UPS
Manufacturer Part Number SM10KAPMA
Manufacturer Website Address
Limited Warranty 1 Year
Form Factor Modular
Load Capacity 10000 VA/10 kW
Manufacturer CyberPower Systems, Inc
Product Model SM10KAPMA
Product Name SM10KAPMA 3-Phase Modular UPS Power Modules
Product Line Smart App Online
Waveform Type Sine Wave
Product Series 3-Phase Power Modules
Rack Height 2U
Brand Name CyberPower
Phase Three Phase
Environmentally Friendly Yes
Environmental Certification RoHS
Product Color Silver, Black
Additional Information Boost Charge Voltage: 2.4 VDC/Cell, Constant Current and Constant Voltage Charge Mode, Float Charge Voltage: 2.25 VDC/Cell, Input Power Factor: 0.99, Output Power Factor: 1, Overload Protection: 105 - 110% Load for 60 min, Material of Construction: Metal, Mounting Hardware: No, Maximum Air Exchange: 4.5 m3 /min, Operating Elevation Note: At ?1000m above sea level, de-rate power by 1% per 100m between 1000m and 3048m, Operating Relative Humidity: 0 - 95 % (non-condensing), Operating Temperature Note: Battery life is halved for every 10°C increase above 20°C, Storage Battery Temperature Note: Optimum battery storage between -15°C and 20°C, UPS Models: SM020KAMFA, SM040KAMFA,
Sound Emission 56 dB(A)
Certifications & Standards Safety: cTUVus
Status Indicators LED Indicators: Rectifier
Overload Protection Yes
Thermal Dissipation 819.96 W
Output Frequency 60 Hz
Input Frequency 70 Hz
Maximum Operating Temperature 104°F (40°C)
Battery Characteristics Hot-swappable
Energy Saving Online ECO Mode Efficiency >97.5%
Maximum Operating Elevation 10000 ft
Storage Relative Humidity 0% - 95%
Storage Temperature -4°F (-20°C) - 158°F (70°C)
Sound Emission (A-Weighted) 56 dB(A)
GTIN 0649532931170
UPC 649532931170
EAN 0649532931170
UNSPSC 39121011
