Sale!

Fortinet FortiGate 7060E-9-DC security appliance with 2 x FPM-7620E processor modules, 2 x FIM-79xxE-C, 2 x manager modules FG-7060E-9-DC

Fortinet FortiGate 7060E-9-DC – Security appliance – DC power – 8U – rack-mountable – with 2 x FPM-7620E processor modules, 2 x FIM-79xxE-C, 2 x manager modules

SKU: FG-7060E-9-DC~PVAR Categories: , Brand: Fortinet

Description

Description: 8U 6-SLOT CHAS W/ 2X FPM-7630E PROC
Fortinet FortiGate 7060E-9-DC – Security appliance – DC power – 8U – rack-mountable – with 2 x FPM-7620E processor modules, 2 x FIM-79xxE-C, 2 x manager modules

The FortiGate 7000E series delivers high-performance, advanced capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage powerful IPS, SSL Inspection, and advanced threat protection to optimize your network’s performance. Fortinet’s security-driven networking approach provides tight integration of the network to the advanced generation of security.

Key Selling Points
Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
Prevents and detects against known attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services
Proactively blocks unknown sophisticated attacks in real time with the Fortinet Security Fabric
Engineered for innovation using Fortinet’s purpose-built security processors (SPU) to deliver advanced threat protection and ultra-low latency
Provides outstanding performance and protection for SSL encrypted traffic
Application aware routing with in-built SD-WAN capabilities to achieve consistent application performance and great user experience
Built-in advanced routing capabilities to deliver high performance with encrypted IPSEC tunnels at scale
Predefined compliance checklists analyze the deployment and highlight practices to improve the overall security posture
Automatically builds network topology visualizations which discover IoT devices and provide complete visibility into Fortinet products

Additional information

Weight 470.32 lbs
Dimensions 25.6 × 17.3 × 14 in
License

No License, UTP, 360 Protection, Enterprise

Duration

Hardware Only, 1 Year, 3 Years, 5 Years

Product Description Fortinet FortiGate 7060E-9-DC - security appliance - with 2 x FPM-7620E processor modules, 2 x FIM-79xxE-C, 2 x manager modules
Device Type Security appliance
Form Factor Rack-mountable
Processor 2 x Fortinet FortiASIC CP9/NP6
Performance Firewall throughput (1518-byte UDP): 630 Gbps u00a6 Firewall throughput (512-byte UDP): 630 Gbps u00a6 Firewall throughput (64-byte UDP): 340 Gbps u00a6 Firewall latency (64-byte UDP): 7 u00b5s u00a6 Firewall throughput: 510 Mpps u00a6 VPN throughput (512-bit IPSec): 100 Gbps u00a6 IPS throughput (HTTP): 360 Gbps u00a6 IPS throughput (enterprise traffic mix): 200 Gbps u00a6 SSL inspection throughput: 100 Gbps u00a6 Application control (AVC) throughput: 160 Gbps u00a6 NGFW throughput: 120 Gbps u00a6 Threat protection throughput: 96 Gbps u00a6 VPN throughput (SSL): 15 Gbps u00a6 SSL inspection throughput: 120 Gbps
Capacity Concurrent TCP sessions: 320000000 u00a6 New TCP sessions per second: 1800000 u00a6 Firewall policies: 200000 u00a6 Gateway to gateway IPSec VPN Tunnels: 40000 u00a6 Client to gateway IPSec VPN tunnels: 64000 u00a6 Virtual domains: 10 (maximum 500) u00a6 Number of FortiClient devices: 20000 u00a6 Number of FortiToken devices: 5000
Power DC 48 - 72 V
Power Redundancy Yes
Bundled with 2 x FPM-7620E processor modules, 2 x FIM-79xxE-C, 2 x manager modules
Processors Installed 2 x Fortinet FortiASIC CP9/NP6
Connectivity Technology Wired
Network / Transport Protocol TCP/IP, UDP/IP, IPSec
Remote Management Protocol CLI
Status Indicators Power, temperature, status, alarm, link/activity, HA
Features Modular design, firewall protection, hot swap module replacement, VPN support, manageable, High Availability, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), web threat protection, application filtering, hot swappable power supply, hot swappable 6 fans
Encryption Algorithm SSL, SHA-1, 256-bit AES, TLS 1.2
Expansion Slots 6 expansion slot
Compliant Standards UL, VCCI, BSMI, cUL, CB, FCC, ICES, RCM
Power Device Internal power supply - hot-plug
Installed Qty 4
Max Supported Qty 6
Voltage Required DC 48 - 72 V
Power Consumption Operational 2330 Watt
Power Provided 1500 Watt
OS Provided FortiOS 5
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 20 - 90% (non-condensing)
