Cisco Meraki MR86 Cloud Managed 802.11ax Wi-Fi 6 Outdoor Access Point

Cisco Meraki MR86 is a cloud-managed 4×4:4 802.11ax Wi-Fi 6 outdoor access point that raises the bar for wireless performance and efficiency.

SKU: MR86~PVAR Categories: , , Brand: Cisco Meraki


Additional information

Weight 3.31 lbs
Dimensions 11.81 × 6.02 × 2.16 in

No License, Enterprise


Hardware Only, 1 Year, 3 Years, 5 Years, 7 Years, 10 Years

Product Description Cisco Meraki MR86 - wireless access point - cloud-managed
Device Type Wireless access point
Form Factor External
Frequency Band 2.4 GHz, 5 GHz
Included Accessories Mounting kit
Power Over Ethernet (PoE) Supported PoE+
Manufacturer Warranty Limited lifetime warranty
Ruggedized Design Outdoor
Connectivity Technology Wireless
Line Coding Format 1024 QAM, OFDMA
Spread Spectrum Method OFDMA
Network / Transport Protocol IPSec
Cloud-Managed Yes
Status Indicators Power, boot state, status
Features Firewall protection, VPN support, firmware upgradable, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), Wireless Intrusion Prevention System (WIPS), DiffServ Code Point (DSCP) support, MU-MIMO technology, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), SU-MIMO technology, opportunistic key caching (OKC), 4x4:4 MU-MIMO technology, packet aggregation, Target Wait Time (TWT)
Encryption Algorithm AES, TLS, TTLS, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP, EAP-SIM, WPA3-Enterprise, WPA3-Personal, WPA3-Enhanced Open
Authentication Method MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-SIM
Compliant Standards CSA, VCCI, ICES-003, EN55024, CISPR 22, RSS-102, FCC Part 15 C, UL 2043, RoHS, FCC Part 2, AS/NZS 4268, FCC Part 15 E, IP67, EN 62311, NCC, EN 300 328, EN 50385, LP0002, RSS-247, EN 301 489-1-17, EN 62479, EN 301 893, EN 55032, AS/NZS 2772, CB 60950, CB 62368, IFT, NOM-208
Antenna External
Interfaces 1 x 1/2.5GBase-T (PoE+) - RJ-45
Power Consumption Operational 18 Watt
Service & Support Limited warranty - advance hardware replacement - lifetime
Min Operating Temperature -40 u00b0F
Max Operating Temperature 131 u00b0F
Humidity Range Operating 5 - 95% (non-condensing)
