Aruba 6100 24G 4SFP+ Switch24 Ports3 Layer SupportedModular33 W Power ConsumptionTwisted Pair, Optical Fiber1U HighRack-… JL678A#ABA


Aruba 6100 24G 4SFP+ Switch
Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks.
Can work as layer 3 routing for scalable network design.
Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters.
Cascade to other network devices through the uplink port to expand your local area network.
Features 24 networking ports to meet the requirements of the most demanding workgroups.
Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing.
Convenient built-in 1/10GbE uplinks and up to 370W of Class 4 PoE for support of IoT devices.
Compact and fanless 12 port model for quiet deployment.
Automated configuration and verification with Aruba NetEdit.
Software defined ready with REST APIs.
Simplify adds, moves and changes with colorless ports.

SKU: JL678A#ABA Category: Brand: Aruba Networks


Aruba 6100 24G 4SFP+ Switch

Aruba 6100 Switch Series

The Aruba CX 6100 Switch Series is modern family of entrylevel access switches ideal for enterprise branch offices andSMB networks. Optimized for reliable, simple and secure access, the CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile and cloud applications.

The CX 6100 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 370W of PoE to support IoT devices such as security cameras and wireless APs, and includes acompact and fanless model ideal for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the CX 6100 also simplifies ownership with no software licensing requirements..

Additional information

Weight 8.092 lbs
Dimensions 7.92 × 17.40 × 1.73 in
Package Contents 6100 24G 4SFP+ Switch, Mounting Brackets,
Product Type Ethernet Switch
Input Voltage 120 V, 230 V
Manufacturer Part Number JL678A#ABA
Manufacturer Website Address
Power Source Power Supply
Limited Warranty Lifetime
Layer Supported 3
Form Factor Rack-mountable, Wall Mountable
Manufacturer Hewlett Packard Enterprise
Product Name 6100 24G 4SFP+ Switch
Network Technology 10/100/1000Base-T, 10GBase-X
Power Consumption 33 W
Product Series 6100
Brand Name Aruba
Expansion Slot Type SFP+
Environmentally Friendly Yes
Environmental Certification RoHS, WEEE
Compatible Rack Unit 1U
Number of Power Supplies Supported 1
Number of Power Supplies Installed 1
Ethernet Technology Gigabit Ethernet, 10 Gigabit Ethernet
Number of Total Expansion Slots 4
Number of SFP+ Slots 4
Modular Yes
Media Type Supported Twisted Pair, Optical Fiber
Total Number of Network Ports 24
Port/Expansion Slot Details 24 x Gigabit Ethernet Network, 4 x 10 Gigabit Ethernet Expansion Slot
Frequency 50 Hz, 60 Hz
GTIN 0190017348698
UPC 190017348698
EAN 0190017348698
UNSPSC 43222612
