Aruba 6100 48G 4SFP+ Switch48 Ports3 Layer SupportedModular44.20 W Power ConsumptionTwisted Pair, Optical Fiber1U HighRa… JL676A#B2E


Aruba 6100 48G 4SFP+ Switch
Gigabit Ethernet port for ultra-fast network speeds.
With Wall mounting feature, you can conveniently install the switch while keeping the wires and cables organized.
Can work as layer 3 routing for scalable network design.
Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters.
Built-in power supply to ensure all components are being supplied with accurate voltage.
Cascade to other network devices through the uplink port to expand your local area network.
Features 48 networking ports to establish large network.
Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing.
Convenient built-in 1/10GbE uplinks and up to 370W of Class 4 PoE for support of IoT devices.
Compact and fanless 12 port model for quiet deployment.
Automated configuration and verification with Aruba NetEdit.
Software defined ready with REST APIs.
Simplify adds, moves and changes with colorless ports.

SKU: JL676A#B2E Category: Brand: Aruba Networks


Aruba 6100 48G 4SFP+ Switch

Aruba 6100 Switch Series

The Aruba CX 6100 Switch Series is modern family of entry level access switches ideal for enterprise branch offices and SMB networks. Optimized for reliable, simple and secure access, the CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile and cloud applications.

The CX 6100 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This layer 2 switch series has convenient built-in high speed uplinks with up to 370W of PoE to support IoT devices such as security cameras and wireless APs, and includes acompact and fanless model ideal for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the CX 6100 also simplifies ownership with no software licensing requirements..

Additional information

Weight 10.556 lbs
Dimensions 9.74 × 17.40 × 1.73 in
Package Contents 6100 48G 4SFP+ Switch, Mounting Brackets,
Product Type Ethernet Switch
Input Voltage 120 V, 230 V
Manufacturer Part Number JL676A#B2E
Manufacturer Website Address
Power Source Power Supply
Limited Warranty Lifetime
Layer Supported 3
Form Factor Rack-mountable, Wall Mountable
Manufacturer Hewlett Packard Enterprise
Product Name 6100 48G 4SFP+ Switch
Network Technology 10/100/1000Base-T, 10GBase-X
Power Consumption 44.20 W
Product Series 6100
Brand Name Aruba
Expansion Slot Type SFP+
Environmentally Friendly Yes
Environmental Certification RoHS, WEEE
Compatible Rack Unit 1U
Number of Power Supplies Supported 1
Number of Power Supplies Installed 1
Ethernet Technology Gigabit Ethernet, 10 Gigabit Ethernet
Number of Total Expansion Slots 4
Number of SFP+ Slots 4
Modular Yes
Media Type Supported Twisted Pair, Optical Fiber
Total Number of Network Ports 48
Port/Expansion Slot Details 48 x Gigabit Ethernet Network, 4 x 10 Gigabit Ethernet Expansion Slot
Frequency 50 Hz, 60 Hz
UNSPSC 43222612
