Aruba 8360-16Y2C Ethernet SwitchManageableTAA Compliant3 Layer SupportedModular325 W Power ConsumptionOptical Fiber1U Hi… JL703A#ABA


Aruba 8360-16Y2C Ethernet Switch
100 Gigabit Ethernet provides high bandwidth performance, ease of use and reliability for your network backbone.
Rack mounting enables you to organize wires & secure cables for professional installation.
Can work as layer 3 routing for scalable network design.
Management capability provides control over setup and configuration of your network.
Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components.
Built-in power supply to ensure all components are being supplied with accurate voltage.
Cascade to other network devices through the uplink port to expand your local area network.
High-performance 2.4Tbps and 1,145 Mpps.
Intelligent monitoring and visibility with Aruba Network Analytics Engine.
High availability with industry-leading VSX redundancy, and redundant power supplies and fans.
Designed for core/aggregation in the campus or Top of Rack or End of Row in data center environments.
MACsec secured connectivity over untrusted domains.
ArubaOS-CX automation and programmability using built-in REST APIs and Python scripts.
Advanced Layer 2/3 feature set includes BGP, OSPF, VRF, and IPv6.
Compact 1U switch with 1/10/25GbE and 40/100GbE connectivity.

SKU: JL703A#ABA Category: Brand: Aruba Networks


Aruba 8360-16Y2C Ethernet Switch
Aruba CX 8360 Switch Series

High Performance Enterprise Campus and Data Center Switch
The Aruba CX 8360 Switch Series offers a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT era. These switches serve the needs of the next-generation core and aggregation layer of campuses, as well as virtual and highly dynamic data center environments. They provide up to 2.4Tbps of capacity, with line-rate Gigabit Ethernet interfaces including 1Gbps, 10Gbps, 25Gbps, 40Gbps, and 100Gbps.

The 8360 series includes industry-leading line rate ports with 1/10/25GbE (SFP/SFP+/SFP28) and 40/100 GbE (QSFP+/ QSFP28) connectivity in a compact 1U form factor. 4x10Gbps and 4x25Gbps break out from 40/100G ports offer advanced flexibility in connectivity and aggregation. These switches deliver a fantastic investment for customers wanting to migrate from older 1GbE/10GbE to faster 25GbE, or from 10GbE/40GbE uplinks to 100GbE ports.

In addition, the 32 x 25G port 8360 models support lowdensity MACsec ports and enable secured connectivity at 10GbE and 25GbE over unsecured domains.

Additional information

Weight 35 lbs
Dimensions 16.00 × 17.40 × 1.73 in
Package Contents 8360-16Y2C Ethernet Switch, 2 x PSU, 3 x Fans,
Product Type Ethernet Switch
Input Voltage 120 V AC, 230 V AC
Manufacturer Part Number JL703A#ABA
Manufacturer Website Address
Power Source Power Supply
Limited Warranty Lifetime
Layer Supported 3
Form Factor Rack-mountable, Surface Mount
Manufacturer Hewlett Packard Enterprise
Product Model 8360-16Y2C
Product Name 8360-16Y2C Ethernet Switch
Network Technology 25GBase-X, 100GBase-X
Power Consumption 325 W
Product Series CX 8360
Brand Name Aruba
Expansion Slot Type QSFP28, SFP28
Manageable Yes
Environmentally Friendly Yes
Environmental Certification RoHS
Compatible Rack Unit 1U
Number of Power Supplies Supported 2
Ethernet Technology 25 Gigabit Ethernet, 100 Gigabit Ethernet
Number of Total Expansion Slots 18
Modular Yes
Media Type Supported Optical Fiber
Port/Expansion Slot Details 16 x 25 Gigabit Ethernet Expansion Slot, 2 x 100 Gigabit Ethernet Expansion Slot
Redundant Power Supply Supported Yes
TAA Compliant Yes
Frequency 50 Hz, 60 Hz
GTIN 0190017387697
UPC 190017387697
EAN 0190017387697
UNSPSC 43222612
