Meraki MR46E Wi-Fi 6 access point cloud-managed MR46E

Cisco Meraki MR46E – Wireless access point – 802.11ac Wave 2 – Wi-Fi 6 – 2.4 GHz, 5 GHz – cloud-managed

SKU: MR46E~PVAR Categories: , Brand: Cisco Meraki


Meraki MR46E Wireless Access Point – High Performance 802.11ax Wireless

The Meraki MR46E Wireless Access Point is a new cloud-managed 802.11ax access point. Carrying 4×4:4 radio setup, it truly raises the bar for performance and efficiency. As a result, it’s ideal for next-generation uses in offices, schools, hospitals, and hotels. It offers high throughput, enterprise security, and simple management.


The Meraki MR46E Wi-Fi 6 access point provides up to 3.5 Gbps* aggregate frame rate. And, it carries 2.4 GHz and 5 GHz radios. A dedicated third radio provides real-time WIDS / WIPS and automated RF optimization. Plus, there’s also a fourth radio that delivers Bluetooth scanning and beaconing. With MR 46 you get cloud management, high performance hardware and multiple radios. Therefore, the MR-46 makes an outstanding platform for the most demanding of uses.
That includes high-density and bandwidth-hungry deployments like voice and high-definition video. The MR Enterprise license includes centralized cloud-based management. Therefore, you will not need an on-site hardware controller for your Meraki MR46E Wi-Fi 6 access point. In addition, you have network-wide visibility and control.
This is a massively scalable bundle, up to thousands of APs. The MR Advanced license includes a device (Enterprise) license for the MR access point. Plus, the Umbrella DNS security and content filtering integration is included. Not surprisingly, the MR46 shares Meraki’s simple set-up, smooth and easy roaming. You’ll probably even experience lowered battery usage!

Meraki MR46E highlights

  • 802.11ax Access Point
  • Up to 3.5 Gbps Aggregate Frame Rate
  • 2.4 GHz & 5 GHz concurrent radios
  • 4×4 radios = Large # of Connections
  • Stateful Layer 3-7 Firewall
  • Great for High-Density Deployments


Meraki MR 46 DataSheet



Learn more

APC SurgeArrest Surge Protection devices

2×2:2, 3×3:3, What do these mean?

(Not so ) free Wi-Fi – Why you shouldn’t connect to an insecure network

What should you look for in an access point?

Learn more about the MR 46!

Additional information

Weight 39.98 lbs
Dimensions 6.1 × 12.1 × 1.4 in

No License, Enterprise


Hardware Only, 1 Year, 3 Years, 5 Years, 7 Years, 10 Years

Product Description Cisco Meraki MR46E - wireless access point - cloud-managed
Device Type Wireless access point
Form Factor External
Frequency Band 2.4 GHz, 5 GHz
Included Accessories Mounting kit
Power Over Ethernet (PoE) Supported PoE+
Manufacturer Warranty Limited lifetime warranty
Connectivity Technology Wireless
Line Coding Format 1024 QAM, OFDMA
Spread Spectrum Method OFDMA
Network / Transport Protocol IPSec
Cloud-Managed Yes
Status Indicators Power, boot state, status
Features Firewall protection, VPN support, firmware upgradable, Wireless Intrusion Detection System (WIDS), Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), Wireless Intrusion Prevention System (WIPS), DiffServ Code Point (DSCP) support, MU-MIMO technology, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), SU-MIMO technology, opportunistic key caching (OKC), 4x4:4 MU-MIMO technology, packet aggregation, security slot (Kensington security lock compatible), Target Wait Time (TWT)
Encryption Algorithm AES, TLS, TTLS, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP, EAP-SIM, WPA3-Enterprise, WPA3-Personal, WPA3-Enhanced Open
Authentication Method MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-SIM
Compliant Standards CSA, VCCI, ICES-003, EN55024, CISPR 22, RSS-102, FCC Part 15 C, UL 2043, RoHS, FCC Part 2, AS/NZS 4268, FCC Part 15 E, EN 62311, NCC, EN 300 328, EN 50385, LP0002, RSS-247, EN 301 489-1-17, EN 62479, EN 301 893, EN 55032, AS/NZS 2772, CB 60950, CB 62368, IFT, NOM-208
Antenna External
Interfaces 1 x 1/2.5GBase-T (PoE+) - RJ-45
Power Consumption Operational 18 Watt
Service & Support Limited warranty - advance hardware replacement - lifetime
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 5 - 95% (non-condensing)
