Cyber Power OL10KRTMB Smart App Online UPS Systems10000VA/10000W, 200240 VAC, Hardwire, 6U, Rack / Tower, Sine Wave, 7 Outlets, LCD, Powe… OL10KRTMB

Cyber Power OL10KRTMB Smart App Online UPS Systems10000VA/10000W, 200240 VAC, Hardwire, 6U, Rack / Tower, Sine Wave, 7 Outlets, LCD, Powe… OL10KRTMB

$6,369.00

CyberPower OL10KRTMB Smart App Online UPS Systems
Capacity: 10000 VA / 10000 W.
Power Factor (PF): 1.0.
Topology: Double-Conversion.
Waveform: Sine Wave.
Output: 200, 208, 220, 230, 240 VAC User Configurable ±2%.
Runtime (half/full): 10 minutes / 3.6 minutes.
Plug type & cord: Hardwire.
Outlets: 7.
Outlet types: 2 × NEMA L6-20R, 4 x NEMA L6-30R, 1 x Hardwire Terminal Block.

SKU: OL10KRTMB Category: Brand: Cyber Power

Description

CyberPower OL10KRTMB Smart App Online UPS Systems

The CyberPower Smart App Online OL10KRTMB is a 6U rack/tower UPS featuring double-conversion topology for seamless power protection, an intuitive maintenance bypass switch design, and a pre-installed RMCARD205. Ensure maximum efficiency and capacity output with a Power Factor rating (PF) of 1. The energy-saving GreenPower UPS™ ECO Mode enables up to 97% efficiency while reducing power consumption and thermal dissipation. Smart battery management charging technology increases battery life up to 50% and replenishes battery charge from 0-90% in five hours.

The OL10KRTMB enhanced LCD control panel functionality provides the ability to change the IP address, view UPS load energy consumptions, and select UPS diagnostic tests.

Variable 4-speed fans provide automatic thermal management, based on power load, to reduce noise. A tamper-proof input circuit breaker ensures power is not turned off unexpectedly during service or maintenance. The OL10KRTMB simplifies installation with a quick start guide, user-friendly lifting straps, and an enhanced hanging rack mount rail system.

The optional BP240VL3U01 Extended Battery Module expands runtime and speeds restoration of full backup power. The OL10KRTMB comes with a three-year warranty (including batteries) and a $300,000 Connected Equipment Guarantee.

Additional information

Weight 349.3 lbs
Dimensions 32.30 × 17.05 × 10.40 in
Application/Usage Server, Server Room, Server Virtualization Infrastructures (VMware, Hyper-V, Citrix), Hyperconverged Infrastructure (HCI), Storage System, Lab Equipment, High-end System Component, Electronic Device, Network Device, VoIP, Network Equipment
Battery Chemistry Lead Acid
Package Contents Smart App Online OL10KRTMB 10000VA Rack/Tower UPS, USB Cable, Serial Cable, Phone Cable, Rack Mounting Hardware,
Product Type Dual Conversion Online UPS
Input Voltage 230 V AC
Manufacturer Part Number OL10KRTMB
Manufacturer Website Address http://www.cyberpowersystems.com
Limited Warranty 3 Year
Output Voltage 200 V AC, 208 V AC, 220 V AC, 230 V AC, 240 V AC
Form Factor Rack/Tower
Load Capacity 10000 VA
Manufacturer CyberPower Systems, Inc
Product Model OL10KRTMB
Product Name Smart App Online OL10KRTMB 10000VA Rack/Tower UPS
Network Management SNMP Manageable
Waveform Type Sine Wave
Product Series Smart App Online UPS
Rack Height 6U
Brand Name CyberPower
Plug/Connector Type Hardwired
Input Voltage Range 200 V AC - 240 V AC
Country of Origin China
Receptacle Type NEMA L6-20R, NEMA L6-30R, Terminal Block
Environmentally Friendly Yes
Environmental Certification RoHS, GreenPower UPS
Product Condition New
Backup/Run Time (Half Load) 10 Minute
Backup/Run Time (Full Load) 3.60 Minute
Replaceable Battery Yes
Energy Star Yes
Typical Battery Recharge Time 5 Hour
Product Color Black
Receptacle Detail 2 x NEMA L6-20R, 4 x NEMA L6-30R, 1 x Terminal Block
Additional Information Hot Swappable: Yes, Replacement Battery Cartridge Quantity: 2, Smart Battery Management (SBM) Mode: Yes, Rail Depth - Max. Mounting: 36.02 in (914.91 mm), Rail Depth - Min. Mounting: 20.47 in (519.94 mm), Weight (lb): 234.3, Maintenance Bypass Module - Dimensions (WxHxD, in): 7.8 x 10.4 x 6.3, Maintenance Bypass Module - Rack Units: 6U, Maintenance Bypass Module - Weight (lb): 13, Battery Module Dimensions - WxHxD (in): 17.05 x 5.2 x 26 in, Battery Module - Rack Units: 3U, Battery Module - Weight (lb): 171.6, Power Module Dimensions - Wu00d7Hu00d7D (in): 17.05 x 5.2 x 26.0 in, Power Module - Rack Units: 3U, Power Module - Weight (lb): 52.8, Backfeed Protection: Yes, Cold Start: Yes, Input Power Factor: 0.99, Voltage Range: 121 V to 139 V, 0% to 25% load, Bypass: Internal Bypass (Automatic and Manual), Crest Factor: 3:1, ECO Mode Voltage Regulation: ±10%, ±15% (configurable), Harmonic Distortion: < 3% at Linear Load, Maintenance Bypass: Yes, Nominal Output Voltage: 198 - 292 VAC, Output Power Factor: 1, Short Circuit Protection: UPS Output Cut off Immediately, Dry Contacts: Yes, Expansion Slot: Yes - RMCARD205 pre-installed, LCD: Multifunction LCD, LED Indicators: Power On (White), Management Cable: USB Cable, Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included), Rotatable LCD Control Panel Option: Yes, SNMP / HTTP Remote Monitoring: Yes - RMCARD205 pre-installed, Software (Free Download): PowerPanel® Business, Material of Construction: Metal, Mounting Hardware: Yes, ECO Mode Thermal Dissipation: 1019 BTU/hr, Online Thermal Dissipation: 3211 BTU/hr, Operating Relative Humidity: 0 - 90 % (non-condensing), Operating Temperature: 32 - 104 °F (0 - 40 °C),
Software Included PowerPanel® Business Edition
Sound Emission 65 dB(A)
Certifications & Standards UL1778 5th Ed.
Dataline Protection RJ-11, RJ-45
Status Indicators Power On (White), Line Mode (Green), Battery Mode (Yellow), Bypass Mode (Yellow), Fault (Red), Replace Battery (Red),
Overload Protection Yes
Surge Energy Rating 2430 J
Thermal Dissipation 941.05 W
Output Frequency 50.25 Hz
Alarm Battery Mode, Low Battery, Overload, UPS Fault
Input Frequency 70 Hz
Battery Size 12V
Battery Capacity 9000 mAh
Maximum Operating Temperature 104°F (40°C)
Serial Port Yes
Number of Batteries 20
Battery Characteristics Sealed
EMI/RFI Noise Filter Yes
Directly Connected Equipment Guarantee $300000Lifetime
DC System Voltage 12 V DC
Energy Saving ECO Mode Efficiency >97%
EPO Port Yes
USB (HID Compliant) Port Yes
Maximum Operating Elevation 10000 ft
Maximum Storage Elevation 50000 ft
Operating Humidity 0% - 90%
Storage Relative Humidity 0% - 95%
Storage Temperature -4°F (-20°C) - 113°F (45°C)
Transfer Time 0 ns
GTIN 0649532620272
UPC 649532620272
EAN 0649532620272
UNSPSC 39121011
