Fortinet FortiGate 4201F-DC security appliance FG-4201F-DC

Fortinet FortiGate 4201F-DC – Security appliance – 40 Gigabit LAN, 100 Gigabit Ethernet, 25 Gigabit LAN – DC power – 3U – rack-mountable

SKU: FG-4201F-DC~PVAR Categories: , Brand: Fortinet


Description: 8X 100GE/40GE QSFP28 SLOTS & 18X 25GE/10
Fortinet FortiGate 4201F-DC – Security appliance – 40 Gigabit LAN, 100 Gigabit Ethernet, 25 Gigabit LAN – DC power – 3U – rack-mountable

The FortiGate 4200F series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network performance. Fortinet’s Security-Driven Networking approach provides tight integration of the network to the new generation of security.

Key Selling Points
Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
Prevents and detects against known attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services
Proactively blocks unknown sophisticated attacks in realtime with the Fortinet Security Fabric integrated AI-powered FortiSandbox
Engineered for Innovation using Fortinet’s purpose-built security processors (SPU) to deliver the industry’s best threat protection performance and ultra-low latency
Provides industry-leading performance and protection for SSL encrypted traffic including the first firewall vendor to provide TLS 1.3 deep inspection
Independently tested and validated best security effectiveness and performance
Received unparalleled third-party certifications from NSS Labs, ICSA, Virus Bulletin, and AV Comparatives
Application aware routing with built-in SD-WAN capabilities to achieve consistent application performance and the best user experience
Built-in advanced routing capabilities to deliver high performance with encrypted IPSEC tunnels at scale
Includes a management console that is effective and simple to use, which provides a comprehensive network of automation and visibility
Provides Zero Touch Provisioning leveraging Single Pane of Glass Management powered by the Fabric Management Center
Predefined compliance checklists analyze the deployment and highlight best practices to improve the overall security posture
Enables Fortinet and Fabric-ready partners’ products to provide broader visibility, integrated end-to-end detection, threat intelligence sharing, and automated remediation
Automatically builds Network Topology visualizations which discover IoT devices and provide complete visibility into Fortinet and Fabric-ready partner products

Additional information

Weight 201.07 lbs
Dimensions 26.2 × 17.2 × 5.2 in

No License, UTP, 360 Protection, Enterprise


Hardware Only, 1 Year, 3 Years, 5 Years

Product Description Fortinet FortiGate 4201F-DC - security appliance
Device Type Security appliance
Form Factor Rack-mountable
Processor FortiASIC CP9/NP7
Hard Drive SSD 2 TB x 2
Performance IPS throughput (enterprise traffic mix): 52 Gbps u00a6 NGFW throughput (enterprise traffic mix): 47 Gbps u00a6 Threat protection throughput (enterprise traffic mix): 45 Gbps u00a6 Firewall throughput (1518-byte UDP): 800 Gbps u00a6 Firewall throughput (512-byte UDP): 788 Gbps u00a6 Firewall throughput (64-byte UDP): 400 Gbps u00a6 IPv6 firewall throughput (1518-byte UDP): 800 Gbps u00a6 IPv6 firewall throughput (512-byte UDP): 788 Gbps u00a6 IPv6 firewall throughput (86-byte UDP): 400 Gbps u00a6 Firewall latency (64-byte UDP): 3.02 u00b5s u00a6 Firewall throughput: 600 Mpps u00a6 VPN throughput (512-bit IPSec): 210 Gbps u00a6 VPN throughput (SSL): 16 Gbps u00a6 SSL inspection throughput: 50 Gbps u00a6 Application control throughput: 135 Gbps u00a6 CAPWAP throughput: 47 Gbps
Capacity Concurrent TCP sessions: 210000000 u00a6 New TCP sessions per second: 1000000 u00a6 Firewall policies: 200000 u00a6 Gateway to gateway IPSec VPN Tunnels: 40000 u00a6 Client to gateway IPSec VPN tunnels: 200000 u00a6 Concurrent SSL VPN users: 30000 u00a6 SSL inspection CPS: 34000 u00a6 SSL inspection concurrent sessions: 9000000 u00a6 Virtual domains: 10 u00a6 Maximum virtual domains: 500 u00a6 Number of FortiSwitches: 300 u00a6 Number of FortiAP devices: 2048 u00a6 Number of FortiAP devices (tunnel): 4096 u00a6 Number of FortiToken devices: 20000 u00a6 Number of registered FortiClients: 50000
Power DC -48 -60 V
Power Redundancy Yes
Processors Installed FortiASIC CP9/NP7
Connectivity Technology Wired
Network / Transport Protocol IPSec, SCTP, IPv4, IPv6
Routing Protocol GRE
Features VPN support, CAPWAP support, Virtual Extensible LAN (VXLAN), Carrier Grade NAT (CGN/CGNAT), IP Security (IPSec) support, DDoS Protection
Encryption Algorithm TLS 1.3
Interfaces 1 x USB u00a6 2 x 1000Base-T (management) - RJ-45 u00a6 2 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet (High Availability) - SFP/SFP+/SFP28 u00a6 2 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet (auxiliary) - SFP/SFP+/SFP28 u00a6 16 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SFP/SFP+/SFP28 u00a6 8 x 40Gb Ethernet/100Gb Ethernet - QSFP+/QSFP28
Compliant Standards UL, VCCI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 A, RCM, USGv6, ICSA SSL-VPN
Power Device Internal power supply - hot-plug
Installed Qty 2
Max Supported Qty 2
Voltage Required DC -48 -60 V
Power Consumption Operational 940 Watt
OS Provided FortiOS
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
Humidity Range Operating 20 - 90% (non-condensing)
