Targus USB-C Universal QUAD HD (QVHD) Docking Stationfor Notebook/Desktop PCUSB 3.2 (Gen 1) Type C4 Displays SupportedFull HD, 2K… DOCK520USZ


Targus USB-C Universal QUAD HD (QVHD) Docking Station
Supports four HD (1920 x 1080 p60) displays or two 2K (2560 x 1440 p50) displays via 4 HDMI ports.
Thunderbolt™ 3 compatible.
1 USB-C 3.0 Port with power (15W non-PD).
4 USB 3.0 ports (1 fast charging) connect essential peripherals.
1 Gigabit Ethernet port.
1 3.5mm combo Audio In/Out for mics, speakers, and earphones.
USB-C to USB-A Cable – makes non-USB-C laptops compatible with Targus USB-C docking stations.
Compact, low-profile form and single connection point reduce workspace clutter.
Works With: PCs, Macs, Chromebooks, and Android Devices and Windows® (10/8.1/7), Mac® OS X (10.12/10.11/10.10), Android™ (5.0 or later), Chrome (R51 or later), Ubuntu Linux.
3 Year Limited Warranty.

SKU: DOCK520USZ Categories: , Brand: Targus


Targus USB-C Universal QUAD HD (QVHD) Docking Station

Boost productivity and performance with the world’s first docking station to deliver four HD extended displays. Ideal for call centers, finance applications and entertainment – and anywhere multiple displays add efficiency – the Targus USB-C™ Universal Quad HD (QVHD) Docking Station maximizes workstation viewing. Dual DisplayLink® DL-3950 chip technology supports four HD (1920 x 1080 p60) displays or two 2K (2560 x 1440 p50) displays. The docking station includes numerous additional ports to connect your essential USB 3.0 peripherals and Ethernet network.

Compact and low-profile, this small-but-mighty dock consumes half the desk space of typical docks, reducing clutter and providing the ease of a single connection point for mouse, keyboard, and more. The rubberized, padded bottom protects against scratches, while the VESA bracket mounting provision allows for use of the Targus VESA Mount Bracket (ACX003GLZ – sold separately) to hold your dock behind your display for even greater space savings. Wide compatibility with virtually any laptop ensures easy deployment and use with Thunderbolt 3™, Display Port Alt-Mode, and USB 3.0, 3.1 and Type-C devices.

Additional information

Weight 2.1 lbs
Dimensions 1.69 × 3.46 × 8.15 in
Package Contents USB-C Universal QUAD HD (QVHD) Docking Station, Quick Start Guide , USB-C to USB-A Adapter (10cm), Black , 1.8 M USB-C Male to USB-C Male 5Gbps Cable , Cable, Input US AC cable cord set, 3pins, 1.8M, C5 connector, Adapter, AC to DC, 20V, 3.25A, 65W ,
Host Interface USB 3.2 (Gen 1) Type C
Product Type Docking Station
Device Supported Notebook/Desktop PC
Manufacturer Part Number DOCK520USZ
Manufacturer Website Address
Limited Warranty 3 Year
Connectivity Technology Wired
Manufacturer Targus Group International
Product Model DOCK520USZ
Product Name USB-C Universal QUAD HD (QVHD) Docking Station
Brand Name Targus
Operating System Supported Windows, macOS, Android, Chrome OS, Linux, Ubuntu
Ethernet Technology Gigabit Ethernet
Number of HDMI Ports 4
Network (RJ-45) Yes
Total Number of USB Ports 6
Number of USB 3.0 Ports 4
Thunderbolt Yes
Number of Displays Supported 4
Number of DisplayPorts 0
Headphone/Microphone Combo Port Yes
Number of RJ-45 Ports 1
Kensington Security Slot Yes
Number of Thunderbolt 3 Ports 0
TAA Compliant No
USB Type-C Yes
Number of Mini DisplayPort 0
Number of USB Type-A Ports 4
Supported Resolutions 1920 x 1080, 2560 x 1440
USB Type-A Yes
Screen Mode Supported Full HD, 2K
GTIN 0092636329679
UPC 092636329679
EAN 0092636329679
UNSPSC 43211602
