Vertiv Geist rPDU 2XPRA200-103D20TL6 20-Outlets PDUMeteredNEMA L6-30P20 x NEMA 6-20R240 V ACHorizontalRack-mountableTAA Compliant 15409VH


Geist rPDU 2XPRA200-103D20TL6 20-Outlets PDU
With PDUs decisions for load balancing and minimizing extra cost can be managed.
Monitor load level efficiently with PDU meter.

SKU: 15409VH Categories: , Brand: Vertiv


Geist rPDU 2XPRA200-103D20TL6 20-Outlets PDU

Metered rPDUs deliver reliable power to critical IT equipment within a rack or cabinet. Includes a local LED display to view real-time power data.


  • Avoid accidental overloads when deploying or moving critical server equipment with instant access to power consumption metrics on the local digital display.
  • The local LED display provides real-time power data for instant feedback when deploying or moving critical IT equipment.
  • Every unit is 100% tested for reliability and functionality.
  • Simple and convenient configuration options for cord lengths and chassis colors.
  • Standard three-year warranty, upgraded to a five-year warranty with product registration.

Additional information

Weight 20 lbs
Dimensions 6.00 × 17.00 × 3.39 in
Product Type PDU
Input Voltage 240 V AC
Manufacturer Part Number 15409VH
Manufacturer Website Address
Limited Warranty 5 Year
Output Voltage 208 V AC
Input Current 30 A
Manufacturer Vertiv
Product Model 2XPRA200-103D20TL6
Product Name rPDU 2XPRA200-103D20TL6 20-Outlets PDU
Mount Type Rack-mountable
Protection Type Overcurrent Protection, Double Pole
Product Series rPDU
Brand Name Geist
Plug/Connector Type NEMA L6-30P
Input Voltage Range 200 V AC - 240 V AC
Country of Origin United States
Receptacle Type NEMA 6-20R
Environmentally Friendly Yes
Environmental Certification RoHS
TAA Compliant Yes
PDU Type Metered
Mounting Orientation Horizontal
Power Rating (Watt) 4900 W
Receptacle Detail 20 x NEMA 6-20R
Plug/Connector Detail 1 x NEMA L6-30P
UNSPSC 39121017
