Vertiv Geist rPDU MUU3E1R5-12CF17-2C20A9H00-S 12-Outlets PDUSwitched Outlet MonitoredIEC 60320 C2012 x Combination C13/C19Network (RJ-45) -… UU30200


Geist rPDU MUU3E1R5-12CF17-2C20A9H00-S 12-Outlets PDU

SKU: UU30200 Categories: , Brand: Vertiv


Geist rPDU MUU3E1R5-12CF17-2C20A9H00-S 12-Outlets PDU

Upgradeable Switched Outlet Level Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering individual outlet level control and a comprehensive view of outlet level power usage via remote network access. Includes environmental monitoring capabilities to obtain real-time environmental metrics. With the Geist Upgradeable hot-swap technology, users may easily update the rPDU technology with the addition of the appropriate Interchangeable Monitoring Device (IMD) as business needs change.


  • Remotely reboot outlets to power cycle unresponsive IT equipment or increase runtime of critical equipment upon power failure with outlet-level control.
  • Reliable power distribution with local and remote outlet-level power monitoring options offer quick access to critical power usage information down to the device level to evaluate energy usage trends and maximize uptime.
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a break in the network chain occurs. Supports up to 40 rPDUs.
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.

More from the Manufacturer

Additional information

Weight 14 lbs
Dimensions 12.00 × 17.00 × 1.72 in
Product Type PDU
Manufacturer Part Number UU30200
Manufacturer Website Address
Form Factor Hot-swappable
Input Current 20 A
Management DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+,
Manufacturer Vertiv
Product Model MUU3E1R5-12CF17-2C20A9H00-S
Product Name rPDU MUU3E1R5-12CF17-2C20A9H00-S 12-Outlets PDU
Mount Type Rack-mountable
Product Series rPDU
Brand Name Geist
Plug/Connector Type IEC 60320 C20
Input Voltage Range 100 V AC - 240 V AC
Country of Origin United States
Receptacle Type Combination C13/C19
Output Voltage Range 100 V AC - 240 V AC
Network (RJ-45) Yes
PDU Type Switched Outlet Monitored
Mounting Orientation Horizontal
Power Rating (Watt) 3600 W
Receptacle Detail 12 x Combination C13/C19
Plug/Connector Detail 1 x IEC 60320 C20
Remote Outlet Switching Yes
GTIN 4061471339552
EAN 4061471339552
UNSPSC 39121017
